    PRODUCTS

    Products R & D capabilities Quality















































    ES061

    Input voltage range:100-240VAC
    Input current range: 0.3A Max
    Input frequency range: 50/60Hz
    Output voltage range: 10-12V
    Output current range: 500mA-2000mA
    Shell size (including pins):L56mm*W72mm*H30.7mm
    No load power consumption:0.3W Max
    Efficiency: 75-88% Min
    Surge: + 1KV
    Safety standard: GB4943.1-2011 GB8898-2011
    Ripple and noise: 200Vp-p Max
    Plug specifications:CN
    Certification:CCC
    ES083

    Input voltage range:100-240VAC
    Input current range: 0.4A Max
    Input frequency range: 50/60Hz
    Output voltage range: 12V
    Output current range: 1000mA
    Shell size (including pins):L48mm*W29mm*H64mm
    No load power consumption:0.15W Max
    Efficiency: 77.76% Min
    Surge: + 1KV
    Safety standard: GB8898-2011 GB/T13837-2012 GB17625.1-2012
    Ripple and noise: 200Vp-p Max
    Plug specifications:CN   Certification:CCC
    ES085

    Input voltage range:100-240VAC
    Input current range: 0.5A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5-5.5V/8-12V
    Output current range: 500mA-2000mA
    Shell size (including pins):L60mm*W26.5mm*H51.4mm
    No load power consumption:0.15W Max
    Efficiency: 73.42-77.76% Min
    Surge: + 1KV
    Safety standard: GB4943.1-2011 GB8898-2011
    Ripple and noise: 200Vp-p Max
    Plug specifications:CN
    Certification:CCC
    ES088

    Input voltage range:100-240VAC
    Input current range: 0.5A Max
    Input frequency range: 50/60Hz
    Output voltage range: 12V
    Output current range: 500mA-2000mA
    Shell size (including pins):L65.3mm*W30.5mm*H60.1mm
    No load power consumption:0.15W Max
    Efficiency: 80.29-82.09% Min
    Surge: + 1KV
    Safety standard: GB4943.1-2011 GB8898-2011
    Ripple and noise: 200Vp-p Max
    Plug specifications:CN
    Certification:CCC
    ES052-Outer shell

    Input voltage range: 100-240V ~
    Input current range: 0.6A Max
    Input frequency range: 50/60Hz
    Output voltage range: 10V-12V
    Output current range: 100-2000mA Max
    Shell size (including pins): L88*W41*H44.1 mm
    No load power consumption: 0.3W Max
    Efficiency: 75-88%
    Surge: + 1KV
    Safety standard: GB4943.1-2011
    GB/T9254-2008
    GB17625.1-2012
    Ripple and noise: 200Vp-p Max
    ES051

    Input voltage range: 100-240V ~
    Input current range: 0.6A Max
    Input frequency range: 50/60Hz
    Output voltage range: 12V
    Output current range: 3A Max
    Shell size (including pins): L88*W41*H44.1 mm
    No load power consumption: 0.3W Max
    Efficiency: 75-88%
    Surge: + 1KV
    Safety standard: GB4943.1-2011
    GB/T9254-2008
    GB17625.1-2012
    Ripple and noise: 200Vp-p Max
    Plug specifications:CN/US  Certification:CCC/UL
    ES033

    Input voltage range: 100-240V ~
    Input current range: 0.6A Max
    Input frequency range: 50/60Hz
    Output voltage range: 10V-12V
    Output current range: 100-2000mA Max
    Shell size (including pins): L50.88*W42.88*H45.8 mm
    No load power consumption: 0.3W Max
    Efficiency: 75-88%
    Surge: + 1KV
    Safety standard: GB4943.1-2011
    GB/T9254-2008 GB17625.1-2012
    Ripple and noise: 200Vp-p Max
    Plug specifications:CN/EU    Certification:CCC/CE
    ES055

    Input voltage range: 12-24V
    Input current range: 2A Max
    Input frequency range: /
    Output voltage range: 5V/9V/12V
    Output current range: 1500-3000mA
    Shell size (including pins):L21*W21*H43 mm
    No load power consumption: 0.1W Max
    Efficiency: 80% Min
    Surge: + 1KV
    Safety standard: EN55032:2015
    Ripple and noise: 100Vp-p Max
    Certification:CE
    ES080

    Input voltage range: 100-240VAC
    Input current range: 0.6A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5v
    Output current range: 3400mA
    Shell size (including pins):L52mm*W40mm*H59.5mm
    No load power consumption: 0.1W Max
    Efficiency: 78% Min
    Surge: + 1KV
    Safety standard: EN55032/EN55024/EN61000-3-2/EN61000-3-3 EN60950-1:2006
    Ripple and noise: 200Vp-p Max
    Plug specifications:EU   Certification:CE
    ES056

    Input voltage range: 12-24V
    Input current range: 1.5A Max
    Input frequency range: /
    Output voltage range: 5v
    Output current range: 3400mA
    Shell size (including pins):L22.8*W22.8*H45 mm
    No load power consumption: 0.1W Max
    Efficiency: 80% Min
    Surge: + 1KV
    Safety standard: EN55032:2015
    Ripple and noise: 100Vp-p Max
    Certification:CE
    ES028

    Input voltage range:100-240VAC
    Input current range: 0.3A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5v
    Output current range: 1000mA
    Shell size (including pins):L44mm*W59.3mm*H35.3mm
    No load power consumption: 0.1W Max
    Efficiency: 73.7% Min
    Surge: + 1KV
    Safety standard: EN55032/EN55024/EN61000-3-2/EN61000-3-3 EN60950-1:2006
    Ripple and noise: 200Vp-p Max
    Plug specifications:EU  Certification:CE
    ES029

    Input voltage range:100-240VAC
    Input current range: 0.5A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5v
    Output current range: 2400mA
    Shell size (including pins):L49mm*W38mm*H48.2mm
    No load power consumption: 0.1W Max
    Efficiency: 78% Min
    Surge: + 1KV
    Safety standard: IEC60950-1:2005 AS/NZS60950-1:2015
    Ripple and noise: 200Vp-p Max
    Plug specifications:AU   Certification:SAA
    ES081

    Input voltage range:12-24V
    Input current range: 2A Max
    Input frequency range: /
    Output voltage range: 5v
    Output current range: 3400mA
    Shell size (including pins):L22.8*W22.8*H53 mm
    No load power consumption: 0.1W Max
    Efficiency: 80% Min
    Surge: + 1KV
    Safety standard: EN55032:2015
    Ripple and noise: 100Vp-p Max
    Certification:CE
    ES718

    Input voltage range: 100-240VAC
    Input current range: 0.3A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5V
    Output current range: 500mA-1000mA
    Shell size (including pins): L30.9*W21.8*H57.8 mm
    No load power consumption: 0.1W Max
    Efficiency: 63.69%-68.17% Min
    Surge: + 1KV
    Safety standard: GB4943.1-2011 GB/T9254-2008 GB17625.1-2012
    Ripple and noise: 200Vp-p Max
    Plug specifications:CN/US  Certification:CCC/FCC
    ES698

    Input voltage range: 100-240VAC
    Input current range: 0.3A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5V
    Output current range: 550mA-1000mA
    Shell size (including pins): L37.6*W22.4*H69.7 mm
    No load power consumption: 0.075W Max
    Efficiency: 69.03%-73.77% Min
    Surge: + 1KV
    Safety standard: EN55032:2015 EN60950-1:2006
    Ripple and noise: 200Vp-p Max
    Plug specifications:EU  Certification:CE
    ES658

    Input voltage range: 100-240V
    Input current range: 0.3A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5V
    Output current range: 550mA-1000mA
    Shell size (including pins): L49.5*W45.6*H40.5 mm
    No load power consumption: 0.075W Max
    Efficiency: 69.08%-73.77% Min
    Surge: + 1KV
    Safety standard: EN55032:2015 EN60950-1:2006
    Ripple and noise: 200Vp-p Max
    Plug specifications:UK
    Certification:CE
    ES568

    Input voltage range: 100-240VAC
    Input current range: 0.3A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5V
    Output current range: 500mA-2000mA
    Shell size (including pins): L33.1*W23.2*H58.1 mm
    No load power consumption: 0.1W Max
    Efficiency: 63.69%-68.17% Min
    Surge: + 1KV
    Safety standard: GB4943.1-2011 GB/T9254-2008 GB17625.1-2012
    Ripple and noise: 200Vp-p Max
    Plug specifications:CN/US   Certification:CCC/FCC/UL
    ES528

    Input voltage range: 100-240V
    Input current range: 0~1.5A
    Input frequency range: 50/60Hz
    Output voltage range: 5V
    Output current range: 1.5-2.4A
    Shell size (including pins): L90*W90*H32 mm
    No load power consumption: 0.5W Max
    Efficiency: 85%-87% Min
    Surge: + 1KV
    Safety standards: IS 13252 (PART 1): 2010 IEC60950-1:2005+A1:2013
    Ripple and noise: 100Vp-p Max
    Plug specifications:CN/US  Certification:CCC/FCC
    ES538-Bright surface - big

    Input voltage range: 100-240VAC
    Input current range: 0.5A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5V
    Output current range: 3A
    Shell size (including pins): L36.1*W23.5*H62 mm
    No load power consumption: 0.3W Max
    Efficiency: 71.22%-73.37%
    Surge: + 1KV
    Safety standard: GB4943.1-2011 GB/T9254-2008 GB17625.1-2012
    Ripple and noise: 200Vp-p Max
    Plug specifications:CN/US  Certification:CCC/FCC
    ES518-Fog surface

    Input voltage range: 100-240VAC
    Input current range: 0.5A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5V
    Output current range: 1500mA-2000mA
    Shell size (including pins): L38.9*W22.4*H79.7 mm
    No load power consumption: 0.075W Max
    Efficiency: 76.88%-79% Min
    Surge: + 1KV
    Safety standard: EN55032:2015 EN60950-1:2006
    Ripple and noise: 200Vp-p Max
    Plug specifications:EU
    Certification:CE
    ES053-Australian rule -small

    Input voltage range: 100-240V
    Input current range: 0.6A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5Vdc or 9Vdc or 12Vdc 3.6-6Vdc/6.2-12Vdc
    Output current range: 1500mA-3000mA
    Shell size (including pins): L38.7*W23.8*H80.3 mm
    No load power consumption: 0.1W Max
    Efficiency: 75-84%
    Surge: + 1KV
    Safety standard: EN55032:2015 EN60950-1:2006
    Ripple and noise: 200Vp-p Max
    ES050-Australian rule -big

    Input voltage range: 100-240V
    Input current range: 0.3A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5V
    Output current range: 100-2400mA Max
    Shell size (including pins): L39*W26*H69.2 mm
    No load power consumption: 0.3W Max
    Efficiency: 78%-88% Min
    Surge: + 1KV
    Safety standard: UL60950-1
    Ripple and noise: 200Vp-p Max
    Plug specifications:AU
    Certification:SAA
    ES032

    Input voltage range: DC9-14V
    Input current range: 3A Max
    Input frequency range: \
    Output voltage range: 4.75-5.25V
    Output current range: 0-2A*2
    Shell size (including pins): L43*W29.5*H21.8 mm
    No load power consumption: 0.3W Max
    Efficiency: 88-90%
    Surge: \
    Safety standard: EN55032:2015 EN60950-1:2006
    Ripple and noise: 100Vp-p Max
    Certification:CE
    ES031

    Input voltage range: DC13.05V
    Input current range: 6A Max
    Input frequency range: \
    Output voltage range: 13.05-13.18V
    Output current range: 0-5A
    Shell size (including pins): L65*W65*H21.8 mm
    No load power consumption: 2W Max
    Efficiency: 88-90%
    Surge: \
    Safety standard: EN55032:2015 EN60950-1:2006
    Ripple and noise: 100Vp-p Max
    Certification:CE
    ES030

    Input voltage range: DC13.05V
    Input current range: 0-5A
    Input frequency range: \
    Output voltage range: 13.05-13.18V
    Output current range: 0-5A
    Shell size (including pins): L89.5*W79.5*H24.5 mm
    No load power consumption: 0.3W Max
    Efficiency: 95-97%
    Surge: \
    Safety standard: EN55032:2015 EN60950-1:2006
    Ripple and noise: 100Vp-p Max
    Certification:CE
    ES025

    Input voltage range: 100-240V
    Input current range: 0~1.5A
    Input frequency range: 50/60Hz
    Output voltage range: 13.05-13.18V
    Output current range: 1000mA/3000mA
    Shell size (including pins): L90*W90*H32 mm
    No load power consumption: 0.5W Max
    Efficiency: 85%-87% Min
    Surge: + 1KV
    Safety standards: IS 13252 (PART 1): 2010 IEC60950-1:2005+A1:2013
    Ripple and noise: 100Vp-p Max
    Certification:CCC
    ES023

    Input voltage range: 100-240V
    Input current range: 0.5A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5V
    Output current range: 2A
    Shell size (including pins): L47.5*W31*H64.3 mm
    No load power consumption: 0.3W Max
    Efficiency: 73.37-74.74% Min
    Surge: + 1KV
    Safety standards: IS 13252 (PART 1): 2010 IEC60950-1:2005+A1:2013
    Ripple and noise: 200Vp-p Max
    Plug specifications:IND  Certification:BIS
    ES022

    Input voltage range: 100-240V
    Input current range: 0.5A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5V
    Output current range: 2000-3100mA
    Shell size (including pins): L44.7*W25.7*H67.3 mm
    No load power consumption: 0.3W Max
    Efficiency: 73.37-76.66% Min
    Surge: + 1KV
    Safety standards: IS 13252 (PART 1): 2010 IEC60950-1:2005+A1:2013
    Ripple and noise: 200Vp-p Max
    Plug specifications:IND    Certification:BIS
    ES020-white

    Input voltage range: 100-240V
    Input current range: 0.3A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5V
    Output current range: 550mA-1000mA
    Shell size (including pins): L66*W48.8*H60 mm
    No load power consumption: 0.075W Max
    Efficiency: 69.03%-73.77% Min
    Surge: + 1KV
    Safety standard: EN55032:2015 EN60950-1:2006
    Ripple and noise: 200Vp-p Max
    ES018

    Input voltage range: 100-240V
    Input current range: 0.5A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5V
    Output current range: 1000mA-2000mA
    Shell size (including pins): L58*W38*H22 mm
    No load power consumption: 0.1W Max
    Efficiency: 71.22%-73.37% Min
    Surge: + 1KV
    Safety standard: GB4943.1-2011 GB/T9254-2008 GB17625.1-2012
    Ripple and noise: 200Vp-p Max
    Plug specifications:CN/US
    Certification:CCC/FCC
    ES010

    Input voltage range: 100-240V
    Input current range: 0.6A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5Vdc or 9Vdc or 12Vdc 3.6-6Vdc/6.2-12Vdc
    Output current range: 1500mA-3000mA
    Shell size (including pins): L49*W27*H67.3 mm
    No load power consumption: 0.1W Max
    Efficiency: 75-84%
    Surge: + 1KV
    Safety standard: EN55032:2015 EN60950-1:2006
    Ripple and noise: 200Vp-p Max
    Plug specifications:UK
    Certification:CE
    ES006

    Input voltage range: 100-240V
    Input current range: 0.5A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5v700mA-1A
    Output current range: 3A/2.7A/2A
    Shell size (including pins): L68.5*W42.5*H23 mm
    No load power consumption: 0.1W Max
    Efficiency: 76.41%-82.10% Min
    Surge: + 1KV
    Safety standard: GB4943.1-2011
    GB/T9254-2008
    GB17625.1-2012
    Ripple and noise: 100Vp-p Max
    Plug specifications:US/EU   Certification:FCC/CE
    ES005

    Input voltage range: 100-240V
    Input current range: 0.5A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5v/9v/12v
    Output current range: 3A/2.7A/2A
    Shell size (including pins): L68.5*W42.5*H23 mm
    No load power consumption: 0.1W Max
    Efficiency: 76.41%-82.10% Min
    Surge: + 1KV
    Safety standard: GB4943.1-2011
    GB/T9254-2008
    GB17625.1-2012
    Ripple and noise: 100Vp-p Max
    Plug specifications:CN/US   Certification:CCC/FCC
    ES011

    Input voltage range: 100-240V ~
    Input current range: 0.6A Max
    Input frequency range: 50/60Hz
    Output voltage range: 6V
    Output current range: 3A Max
    Shell size (including pins): L50.88*W42.88*H45.8 mm
    No load power consumption: 0.3W Max
    Efficiency: 75-88%
    Surge: + 1KV
    Safety standard: EN55032:2015
    EN60950-1:2006
    Ripple and noise: 200Vp-p Max
    Plug specifications:UK   Certification:CE
    ES027

    Input voltage range: 100-240V ~
    Input current range: 0.3A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5V
    Output current range: 1500mA-2400mA
    Shell size (including pins): L50.88*W42.88*H45.8 mm
    No load power consumption: 0.3W Max
    Efficiency: 75-81%
    Surge: + 1KV
    Safety standard: EN55032:2015
    EN60950-1:2006
    Ripple and noise: 200Vp-p Max
    Plug specifications:UK  Certification:CE
    ES019

    Input voltage range: 100-240V
    Input current range: 0.6A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5Vdc or 9Vdc or 12Vdc
    3.6-6Vdc/6.2-12Vdc
    Output current range: 1500mA-3000mA
    Shell size (including pins): L62.3*W46*H23 mm
    No load power consumption: 0.1W Max
    Efficiency: 75-84%
    Surge: + 1KV
    Safety standard: EN55032:2015
    EN60950-1:2006
    Ripple and noise: 200Vp-p Max
    Plug specifications:CN/US  Certification:CCC/FCC
    ES015

    Output voltage range: 100-240VAC
    Input current range: 0.6A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5Vdc or 9Vdc or 12Vdc
    3.6-6Vdc/6.2-12Vdc
    Shell size (including pins) /L38.7*W23.8*H80.3 mm
    No load power consumption /0.1W Max
    Efficiency: 75-84%
    Surge: + 1KV
    Safety standard: EN55032:2015
    EN60950-1:2006
    Ripple and noise: 200Vp-p Max
    Plug specifications:EU   Certification:CE
    ES038

    Input voltage range: 12-24V
    Input current range: 2A Max
    Input frequency range: 50/60Hz
    Output voltage range: 5V
    Output current range: 1000-2400mA
    Shell size (including pins): L25*W20*H44 mm
    No load power consumption: 0.1W Max
    Efficiency: 73.36% Min
    Surge: + 1KV
    Safety standard: EN55032:2015
    Ripple and noise: 100Vp-p Max
    Certification:CE
    ALL MORE >>

    SUSTAINABILITY

    Sustainable development for Core competitiveness of Enterprises
        Different from the exhaustible material resources, the endless corporate culture and entrepreneurial spirit are the pillars that support the sustainable development of enterprises. Closely related to our environmental and social responsibilities, we must have a set of persistent core values, a cultivating corporate culture, and an act of consciously instilling core values.

        The competitiveness of human resources has become a decisive factor for the sustainable development of enterprises. Shenzhen East Sun Electronic always strictly abides by laws and regulations, and respects labor rights and interests. Professionals who work hard there to achieve organizational goals are crucial factors in the company's success. With the rapid development of information economy and technology, enterprises have become more and more aware of the important value of “Human” who create invention technology. To ensure the demand for talents, enterprises should not only focus on capital and quality, but also the most important thing-- human resources will become the focus of enterprises. Therefore, human resources have already become the decisive factor for the sustainable development of enterprises.

        East Sun Electronic is committed to environmental friendliness in product design and production. We focus on improving the charging efficiency, quality and overall production operational efficiency of the power adapter. We infiltrate environmentally friendly ideas into every aspect of production management and establish a value of “co-construction and sharing” distribution criteria to provide customers with efficient and complete power adapter solutions.

    Contact Us

    Shenzhen
    Add: Building B, No. 88, Xingye 1st Road, Fenghuang 1st Industrial Area, Fuyong Town, Bao'an District, Shenzhen, Guangdong Province, P. R. China
    Tel: 0755-89474180
    Email: hl@sz-dcdz.com

    Sichuang
    Add: 17 th Building, B zone, , Lingang Economic and Technological Development Zone, Yibin City, Sichuang Province, China
    Tel: TBD
    Email: hl@sz-dcdz.com

    India
    Add: Gat 330,Nanekarwadi,Chakan,Pune410501,MH,india
    Tel: +91 838 090 9833
    Email: hl@sz-dcdz.com

    Recruitment
    baidu
    Navigation
    HOME ABOUT US PRODUCTS SUSTAINABILITY Contact Us
    ABOUT US
    Our Company History Corporate Culture Team Demeanor Partners
    PRODUCTS
    Products R & D capabilities Quality
    SUSTAINABILITY
    Business Philosophy Environment Philosophy
    NEWS & EXHIBITION
    Company News Industry News
    Contact Us
    Contact Us Recruitment

    © 2018.EASTSUN . All Rights Reserved. Legal Stuff

    陇ICP备15002349号-1
